High Efficiency Stone Impact Crusher For Vibrating Screen Machine Grading
Attention: This is a non-standard machine, which can be designed and manufactured by customers' concrete requirements.
Product Description
Impact crusher is a new kind of high efficient crusher, which is developed from the hammer crusher and it is used widely in the cement industry. Usually it is used for the corase crushing, secondary crushing and fine crushing of the mid-hard and soft rock, such as limestone, sandstone,coal and clinker. It is samll in size, simple in structure and high in crushing ratio, effective in energy saving, high in capacity,uniform in particles and selective in ore crushing.
Main Advantages
1. Top Technology, Unique Design
In-pit crushing and conveying adopts world-class production technologies. It is made up of high-end materials. The design of heavy-duty rotor and strict checks allow the rotor to have high quality. Meanwhile, the unique fixed device makes the hammer more reliable.
2. Simplified Technological Process, Wide Applications
The two-cavity crushing of Impact Crusher can simplify the technological process of coarse and medium-coarse crushing while the three-cavity crushing makes Impact Crusher perform exceptionally well in fine and superfine crushing. Two kinds of crushing cavities can meet the vast majority of coarse, medium and fine crushing operations.
3. Semi-Automatic Operation Makes Maintenance Easy And Convenient
In-pit crushing and conveying can equip the hydraulic control system. By the hydraulic device, the size of discharge opening and the discharging granularity can get controlled quickly. Besides, the automatic hydraulic jacking device is helpful for quick replacement of vulnerable parts like the hammer so that the downtime for maintenance can be shortened indirectly.
4. Cast Steel Structure, High Holding Capacity
In-pit crushing and conveying 's bearing seat uses integral cast steel structure, which ensures stable operation. Larger bearings boast higher holding capacity.
5. Digitalized Processing, Higher Precision
There are tens of lines of numerical controlling machine tools. Operations such as steel plates' cutting, bending, planing, milling and paint spraying are all controlled numerically. The machining precision is high, especially for the core parts.
Application Industries
1. Mainly application industries: cement industry, building materials, mining, fertilizer industry, etc.
2. Mainly application materials: limestone, gypsum, clinker, calcium phosphide, dolomite, perlite, etc.
Technical Parameters
| Model | Dimension (mm) |
Feeding size(mm) | Max material size(mm) | Capacity (t/h) |
Motor power(kw) | Weight(kg) |
| PF-0607 | 644*740 | 320*770 | 100 | 10-20 | 30 | 10216 |
| PF-0807 | 850*700 | 400*730 | 300 | 15-30 | 30-45 | 11138 |
| PF-1008 | 1000*800 | 400*830 | 300 | 30-50 | 37-55 | 12206 |
| PF-1010 | 1010*1050 | 400*1080 | 350 | 50-80 | 55-75 | 13138 |
| PF-1210 | 1250*1050 | 400*1080 | 350 | 70-120 | 110-132 | 15200 |
| PF-1212 | 1250*1250 | 400*1300 | 350 | 100-150 | 132-160 | 17025 |
| PF-1214 | 1250*1400 | 400*1430 | 400 | 130-180 | 160-200 | 19015 |
| PF-1315 | 1320*1500 | 860*1520 | 500 | 160-250 | 180-260 | 24600 |
| PF-1320 | 1320*2000 | 860*2030 | 500 | 300-350 | 300-375 | 29800 |
| PF-1520 | 1520*2000 | 980*2980 | 700 | 400-500 | 400-480 | 38600 |
Note:
In order to recommend the best suitable design for you, please kindly tell me:
1.What is your raw material to be crushed, it's soft stone (like limestone, dolomite) or hard stone (like granite, basalt, river stone, etc)?
2.What is the maximum feed size of your raw material?
3.What is the output size you want?
4.How much handling capacity per hour you want?
5.Are you the end user or you recommend the machinery to your clients?
